Multi-channel 100V slave amplifier with independent outputs for 100V or 4-16 Ohm speakers. Each amplifier channel has its own independent line input, which can be switched to a global auxiliary, providing the option of the same input to several of the amplifier channels if required. A paging microphone input is provided for voice alerts and a 24V mute terminal can be connected to an alarm panel for emergency evacuation override. Class D circuit design and efficient toroidal transformers have enabled a design which fits into a 1U rack-mount housing. The RMS-series amplifiers can be applied as high power slave units or equally as a fully independent zoning system for a multi-room installation.Power supply[tab]170-264Vac, 50/60Hz (IEC)[br]Auxiliary input[tab]L+R RCA[br]Mic controls[tab]Gain, Bass, Treble & Vox (rear panel)[br]Output controls[tab]Level, Bass, Treble & Ch/Aux switch[br]Microphone input[tab]Balanced XLR (rear panel)[br]Phantom power[tab]+20V switchable (paging mic)[br]Emergency control[tab]24V mute contacts (Euroblock terminal)Power rms : 100V line[tab]2 x 120W[br]Power rms : 4 Ohms[tab]2 x 120W[br]Output connection[tab]2 x 100V or 4 Ohm (Euroblock terminal)[br]Weight[tab]5.04kg[br]Dimensions[tab]482 x 252 x 42mm[br]Channel inputs[tab]2 x L+R RCA or balanced terminal[br]Auxiliary output[tab]L+R RCA[br]Fuse[tab]T3.15AL
